Khoom Txheej Txheem
Siab ruaj khov
1. Chh torsion-resistant loj loj channel hlau, high-txoj hauj lwm stacking yog ruaj khov dua;
2. Finite keeb optimized txhawb cov khaub lig, muaj zog torsion tsis kam thiab lub zog siab dua lub zog.
Siab efficiency
1. Vector tswj, sai teb hauv kev ua haujlwm;
2. High-power-power Lifting Tsav, Txhim Kho Kev Ua Haujlwm;
3. Hauv kauj thiab hluav taws xob hluav taws xob braking, rhiab thiab tsis muaj zog;
4. Kev tswj kev cai, txo cov haujlwm ua haujlwm ntau, txhim kho kev ua haujlwm zoo,
Tsawg Zog Kev Siv Hluav Taws Xob
1. Vector tswj, muaj zog siv lub zog;
2. Lub cev muaj zog hloov kho braking, lub zog rov qab, txhim kho kev siv hluav taws xob;
3. Tsawg-txheej txheem txheej txheem hluav taws xob tam sim no, txo qis sab hauv kev tiv thaiv.
Kev Pom Dav Ntawm Saib
1. Ua lub zeem muag tsav, muaj kev nyab xeeb;
2. Cov stacking lub zeem muag dav dav, ntau dua cov kev sib tw siab;
3. Lub gantry pipeline offlet muaj kev siv rau qhov chaw pom;
4. Tus ntoo khaub lig me me-nqaj tus qauv tsim muaj cov haujlwm ua haujlwm loj ntawm kev pom.
| tus qauv | Lub thawv loj \/ cm | |
| Fais Fab Ntaus | noj fai fab | |
| Hom Kev Lag Luam Yam | ||
| Nyob Rated Load | Kg | 2500 |
| Load Center nrug | lub hli | 600 |
| Qhov hnyav (suav nrog roj teeb) | Kg | 3500 |
| Mast qhov siab tom qab kev txo qis | lub hli | 2799 |
| Qhov siab tshaj Lifting qhov siab ntawm tus qauv mast | lub hli | 6500 |
| Mast qhov siab thaum tsa mus rau txoj haujlwm siab tshaj plaws | lub hli | 7565 |
| Kom siab ntawm lub ru tsev tiv thaiv (alarin) | lub hli | 2210 |
| Lub tsheb ntev |
lub hli |
2591 |
| Tshaj dav dav | lub hli | 1260/1350 |
| Rab rawg ntev | s/ e/ l | 40/120/1070 |
| Sab nraud dav ntawm backstop | lub hli | 990 |
| Qhov dav dav ntawm diav rawg | lub hli | 250/770 |
| Deb ntawm lub log npab | lub hli | 915 |
| Dav ntawm txoj cai-lub kaum sab xis sib nraus channel (pallet yog 1000 ntev × 1200 qhov dav) | lub hli | 2950 |
| Dav ntawm txoj cai-lub kaum sab xis sib nraus channel (pallet yog 800 dav × 1200 ntev) | lub hli | 3000 |
| Tig hluav taws xob vojvoog | lub hli | 1960 |
| Tsheb ntev (tsis suav nrog rab diav rawg) | lub hli | 2138 |
| Mus ncig ceev, tag nrho load \/ tsis muaj thauj khoom | KM \/ h | 9/9.5 |
| Lifting ceev, tag nrho load \/ tsis muaj thauj khoom | m/s | 0.35/0.5 |
| Txo kev nrawm nrawm, tag nrho thauj \/ tsis muaj thauj khoom | m/s | 0.41/0.38 |
| Cov qib siab tshaj plaws nce qib, tag nrho load \/ tsis muaj thauj khoom | % | 10/15 |
| Roj Teeb Hluav Taws Xob \/ Nominal Peev Xwm | V \/ ah | 48/700 |
